ESP32-P4-Module Development Board with 5MP OV5647 Camera Speaker Supports for Wi-Fi6/BLE POE Interface

This product is a multimedia development board based on ESP32-P4, integrated with ESP32-C6, supporting Wi-Fi 6 and Bluetooth 5 wireless connections. It provides a rich set of human-computer interaction interfaces, including MIPI- PWM, MCPWM, , ADC, UART, TWAI, etc. In addition, it supports USB OTG 2.0 , reserves an RJ45 Ethernet interface for expandable PoE, and has an onboard 40PIN GPIO expansion interface, which is compatible with some for HAT expansion boards to achieve a range of application adaptation.<br>ESP32-P4 uses a 400MHz dual-core RISC-V processor, supports a maximum of 32MB PSRAM, and has peripherals such as USB 2.0, MIPI-/, and 264 encoding to meet the needs of low-cost, high-performance, and low-power multimedia development.<br>In addition, ESP32-P4 integrates digital signature peripherals and a dedicated key management unit to data and operation security. ESP32-P4-Module-DEV-KIT is designed for high-performance and high-security applications to meet the needs of embedded systems in human-computer interaction, edge computing, 10 expansion, etc. (Integrated Image Signal Processor ISP), MIPI-, SPI, I2S, I2C, LED<br>The product appearance and printed words depending on the batch, but this does not affect use.<br>Colour:As Shown<br>Material:PCB<br><br>Package Contents:<br>1 * ESP32-P4-Module<br>1 * Speaker<br>1 * OV5647 Camera<br><br>Only the above package content, other products are not included.<br>Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

• Chip package stacked 32MB PSRAM, module integrated 16MB Nor Flash
• 2*20 pin headers on the board, 28 remaining programmable GPIOs
• Common peripheral interfaces such as MIPI-, MIPI-, USB 2.0 OTG, Ethernet, SDIO 3.0, SD card slot, microphone, speaker terminal and battery terminal are brought out on the board
• High-performance MCU with RISC-V 32-bit dual-core and single-core processors
• Powerful image and voice processing capabilities, image and voice processing interfaces include JPEG codec, pixel processing accelerator (), image signal processor (ISP), H264 video encoder
